9. Specifi cations

9-1. Rotary Magnescale Specifi cations

Item
Output signal
Data format
Motor temperature detection
Detecting method
Accuracy (at 20 °C)
Resolution
Count direction
Response revolution
Operating temperature range
Storage temperature range
Vibration resistance
Shock resistance
Degree of protection
Power supply voltage
Current consumption
Inrush current
Power supply protection
Dimensions
Cable length
Output connector
Compliant connector
Moment of inertia
Mass
The information here is subject to change without notice.
RS97-1024EGZ Series
RS97-1024EGZ Series
Compliant with SIEMENS DRIVE-CLiQ
DRIVE-CLiQ single-turn absolute format
Not available
Magnetic (MR sensor)
±2.5 s
23 bit
Addition count when stator is fi xed and rotor is rotating clockwise
(Given along with the reference point output position on outside dimensions)
5000 min -1
0 °C to +60 °C
–10 °C to +60 °C
2
150 m/s (50 Hz to 2000 Hz)
2
1000 m/s (11 ms)
IP65
DC 24 V (DC 17 - 30.8 V) (Compliant with SIEMENS DRIVE-CLiQ)
150 mA or less
4 A max. (when the power supply rising time is 10 ms)
In the case of errors such as a reverse-connected power supply or over-voltage,
the internal fuse is cut to protect the power being supplied and wiring.
96 mm (inner diameter) × 20.15 mm (thickness) (For details, see section 10,
"Outside Dimensions.")
1 m / 2 m (max. total length of 30 m using extension connection cables)
SACC-M12MS-8Q SH by PHOENIX CONTACT Inc.
SACC-M12FS-8Q SH by PHOENIX CONTACT Inc.
–4 2
9 × 10 kg m or less
•
2 kg or less (rotor: 0.2 kg, stator: 1.7 kg)
