Motherboard Layout (AD2700B-ITX)
17.0cm (6.7 in)
USB 3.0
T: USB2
B: USB3
18
USB 2.0
Top:
T: USB0
RJ-45
B: USB1
AUDIO
CODEC
17
1
CPU Fan Connector (CPU_FAN1)
2
CPU Heatsink
3
Chassis Fan Connector (CHA_FAN1)
4
2 x 204-pin DDR3 SO-DIMM Slots
(DDR3_A1, DDR3_A2, Black)
5
ATX Power Connector (ATXPWR1)
6
SATA2 Connector (SATAII_2, Blue)
7
USB 2.0 Header (USB6_7, Blue)
8
Infrared Module Header (IR1)
9
System Panel Header (PANEL1, White)
10
Consumer Infrared Module Header (CIR1)
2
ASRock AD2700B-ITX / AD2500B-ITX Motherboard
1
ErP/EuP Ready
CPU_FAN1
Super
IO
RoHS
LAN
PHY
CMOS
Battery
16Mb
BIOS
AD2700B-ITX
HD_AUDIO1
PCI1
DX10.1
16
11
12
13
14
15
16
17
18
2
3
CHA_FAN1
SATAII_1
SATAII_2
1
USB6_7
IR1
1
1
USB4_5
PLED PWRBTN
1
CIR1
1
HDLED RESET
PANEL 1
CLRCMOS1
SPEAKER1
1
1
Design in Taipei
15
14
13
12
11
Clear CMOS Jumper (CLRCMOS1)
Chassis Speaker Header
(SPEAKER 1, White)
USB 2.0 Header (USB4_5, Blue)
SATA2 Connector (SATAII_1, Blue)
16Mb SPI Flash
PCI Slot (PCI1)
Front Panel Audio Header
(HD_AUDIO1, White)
Intel NM10 Express Chip
4
5
6
7
8
9
10
