Care And Maintenance - EINHELL KSS12/1 Bedienungs- Und Wartungsanleitung

Anleitung KSS 12/1 19.03.2003
R = reverse (anticlockwise) to loosen screws
F = forward (clockwise) to tighten screws
Apply the drive bit to the screw head and press the
ON/OFF switch.
Carefully insert the bolt or nut in the thread before
you actuate the electric screwdriver. A torque of
approximately 40-50 Nm per pulse is generated on
standard bolts of size M12/M14. On motor cars, each
bolt should be tightened with two pulses. Each bolt
should then be checked with one additional pulse. A
total torque of between 120 and approximately 150
Nm is thus achieved.
Three pulses are recommended on heavy vehicles
(e.g. luxury cars, off-road vehicles, etc.). Each bolt
should then be tightened in diametrically opposed
order with one additional pulse. A total torque of
approximately 170 - 230 Nm is thus achieved.
Check the threaded connections for signs of damage
after tightening.
Important!
Always tighten and check wheel nuts with a torque
wrench set to the torque specified by the
manufacturer of the vehicle in question.

7. Care and maintenance

Wherever possible, clean the surface with only a soft
dry cloth - do not use aggressive solvents. If abso-
lutely necessary, use a slightly damp rag to remove
dirt.
The following are excluded from the
warranty:
Wearing parts
Damage resulting from improper use or tampering
by third parties
