ENGLISH

DESCRIPTION OF OPERATION

POW ON SEL (POWER ON SELECTION)
6
The amplifier can be turned on/off by using the following methods:
SPK: Slide the switch into position SPK, if you want to turn on/off the amplifier through
the CH1 input channel of the high level speaker inputs and its Auto Turn-On function.
Refer to page 8 and section 3 for more details.
REM: Slide the switch into position REM, if you want to turn on/off the amplifier through
the REM and a turn-on signal from head unit/car stereo.
Refer to page 9 and section 5 for more details.

INPUT SENSITIVITY

7
With these controllers you can adjust the input sensitivity for each analog input section. This function
is suited to match the output voltage of the connected signal source with the amplifier.
CLIP
8
This LED lights up red if one of the six high level inputs (CH1-4 & CH5/6) is overdriven. The LED has
no function when an input signal is applied to the Optical input and the Bluetooth™ input. If this LED
lights up reduce the input sensitivity by using the regarding controller Input Sensitivity until the LED
goes out.
AUX IN
9
These stereo RCA inputs are suited for a auxiliary low level input signal from an external stereo pre-
amplifier source such as a game console or a media player. The input sensitivity adjustable from 2 to
15 V RMS.
CH7 /CH8 OUT (PROCESSED BY DSP)
10
Use these 2CH pre-amplifier RCA outputs for driving an additional amplifier or an active powered
subwoofer.
10
6 7
8
9 10 11 12 13 14
