When selecting the installation location, make sure that an atmospherically vented
drain is nearby.
Also take into account the door hinge for the arium
when selecting the installation location. If the door hinge needs to be retrofitted
because of the installation location, this can be performed by Sartorius Service.
Wall Mounting Bracket for arium
An optional wall mounting bracket (H2O-ATB) is available for arium
system installation.
The wall mounting bracket for the bagtank 20 can only be used for mounting and
attaching the arium
mounting the unit on a wall, make sure that the mounting surface and fasteners
selected are capable of supporting a minimum of 100 kg (220 lbs). Inadequate
support and/or fasteners may result in injury to the operator and damage to the
equipment.
The figure shows the wall mounting bracket with an attached arium
Wall installation:
− Use the pre-drilled slotted holes in the wall mounting bracket to mount the
− Fasten the wall mounting bracket to the wall using suitable screws and dowels
− Position the arium
− Secure the arium
manuals search engine
bagtank 20. Do not add additional load to the bracket. When
®
bracket to the wall.
(ensure that it is horizontally aligned).
bagtank 20 on the wall mounting bracket attached to the
®
wall. The device feet on the bagtank can be used for proper alignment of the
bagtank on the wall mounting bracket. They must fit into the holes on the wall
mounting bracket without being jammed or wedged.
bagtank to the wall mounting bracket. Use the screws
®
provided for this.
bagtank (direction it opens)
®
bagtank 20
®
Installation Instructions arium
Installation
bagtank 20
®
® bagtank 20
bagtank 7
®
