English EX-1181HMS
3. Layout, Connections & Jumper Settings

3.1 Layout

Front:
4x USB 3.1 (Gen1)
Downstream A-Port
Back:
Power LED
+7V up to +48V
1x USB 3.2 Gen1
T-Block for optional
Upstream B-Port
external Power Supply

3.2 Connections

+7V to +48V T-Block:
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
+7V to +48V GND (Ground)
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
10
