MUE2-S01 adjustable rearset left
Teileliste/ Partlist
pos
article no.
description
qty.
[pcs.]
1
1
MUE2-GL-S01-*
basic plate
1
2
CAR-08-*
heel protector
1
3
UV-06-*
adjustment plate
1
4
VST-03-L-*
adjustment nut left
1
5
SPN-03-*
nut
1
6
US-49-*
gear lever
1
7
UEX-01-*
excenter
1
8
UTR-15-*
gear lever toe piece
1
9
RG-810-*
footrest joint
1
10
UF-24-*
footrest
1
11
UF-ST-01-*
plug
1
12
RG-BO-01
bolt RG
1
13
SPN-8-8
special nut
1
14
SPS-17
adapter
2
15
FDS-5
pressure piece
1
16
VD-117S
spring
1
17
SIF-19078
pull spring
1
18
GAKFL6
ball and socket bearing
1
19
M8x16-912-VA
cylinder bolt
1
20
M8x45-7991-VA-TX
countersunk bolt
1
21
M6x16-7991-VA-PRE10-1
countersunk bolt
2
22
M8x20-14583-VA-TX
oval-head bolt
M6x20-7380-VA-TX-
2
23
oval-head bolt
PRE10-1
2
24
M6x10-7380-VA-TX
Flathead bolt
1
25
M4x8-14583-VA-TX
oval-head bolt
1
26
M6-934-L-VA
nut lh
1
27
EHP81D
nut
1
28
ULS-8,4-VA
washer
1
29
ULS-6,4-VA
washer
1
27
5
15
22
14
6
13
29
18
23
26
23
7
8
2
24
28
16
3
12
9
25
19
10
11
21
4
20
17
