Black - MW
Col Progr
Jump/Fade
000 - 255
Mus Progr 00 - 10
Red – 125 - 255
Green – 125 - 255
White Bal
Blue – 125 - 255
White – 125 - 255
Temperat xxC
Sys Info
Cur Power xxx%
Economy ON/OFF
Dis Perm ON/OFF
Def.Set YES/NO
Wireless Setting
This device is prepared for wireless data transmission (QuickDMX) ex works. If you wish to de-activate
QuickDMX control, you can select the function "Power" – "Off". With the function "Power" – "On" you can
log in the wireless receiver to a wireless transmitter, the fixture can now receive the wireless DMX signal.
The QuickDMX status indicator shortly flashes red, green and blue. Afterward, it lights permanently
according to the selected transmission channel.
Set each transmitter and receiver to the same transmission channel. For this purpose, select the "ID Set"
function.
Internal programs / blackout
Black Blackout
Pty 1 Red Green Blue
Pty 2 Cyan Magenta Yellow
Red Green Blue Cyan
Pty 3
Magenta Yellow
Pty 4 Red Green Blue White
Rainbow Red, Yellow,
Rbw Green, Cyan,
Magenta
RD Red Dark
RG Red Green
RB Red Blue
RY Red Yellow
RC Red Cyan
RM Red Magenta
RW Red White
GD Green Dark
GB Green Blue
GY Green Yellow
GC Green Cyan
GM Green Magenta
GW Green White
Jump (000 – 255)
Switching colors with increasing speed;
Fade (000 – 255)
Fading colors with increasing speed
Sound control with increasing microphone sensitivity
White balance
Default setting: RGBW = 255
Internal temperature of the device
Remaining battery power in percent
Power-save mode
ON - power save mode, 50 % power
OFF - full power
Display shutoff
ON - display does not shut off
OFF- Shuts off the display after 30 seconds
Press the Menu button to reactivate the display.
Reset to factory settings incl. Wireless Unlink
32/40
BD Blue Dark
BY Blue Yellow
BC Blue Cyan
BM Blue Magenta
BW Blue White
Blue, WD White Dark
WY White Yellow
WC White Cyan
WM White Magenta
YD Yellow Dark
YC Yellow Cyan
YM Yellow Magenta
YW Yellow White
CD Cyan Dark
CM Cyan Magenta
CW Cyan White
MD Magenta Dark
MW Magenta White
00128199, Version 1.0
