POWER SUPPLY
The device can be operated with mains voltage and for mobile use via the internal rechargeable battery.
The device uses an auto-range power supply that accepts input voltages between 100 und 240 volts.
1
Connect the device via the mains cable to a grounded mains socket.
2
Switch on the device on using the power button.
3
Do not connect the unit to the mains voltage via a dimmer. For a more convenient operation, use a mains
outlet which is switchable.
4
The jack POWER OUT allows for power supply of further devices. To interconnect several devices,
connect the jack POWER OUT to the input POWER IN of the next unit until all units are connected.
Matching power cables are available as accessories. In this manner, up to 8 devices can be linked at
230/240 input voltage and up to 4 devices at 110/115 input voltage.
Rechargeable Battery Operation
Prior to operating the device off mains for the first time, the rechargeable battery must be fully charged.
1
Switch on the device with the power switch. The operating time of the battery depends on the operating
mode and the ambient temperature (max. 17 hours). After the operation, switch the device off.
2
For charging the battery, connect the device to a power outlet via the enclosed power unit. Charging
time is 3.5 hours. The device may be operated during the charging procedure.
3
The device features a protective circuit for charging which prevents overload of the rechargeable
battery. However, disconnect the device from the mains after charging. Otherwise there will be a low
current consumption even if the device is switched off.
4
The device will heat up during charging; this is normal.
5
To prevent damage to the battery by deep discharge, recharge a battery completely discharged as soon
as possible. Do not store the unit with the battery completely discharged and regularly recharge the
battery in case of long storage.
Maximum battery run time
17 hours
Battery status
The battery charging status is indicated on the display. The battery charging status is indicated by four
levels. If all four levels are lit, the battery is fully loaded. If only one level is lit the battery is going flat soon. In
this state, the device can be operated for a few minutes. Then an emergency switch-off deactivates the
device to protect it from total discharge.
Recharge time
3.5 hours
29/40
00128199, Version 1.0
