7.9 Attaching Sandal
Raisers
If sandal raisers have been ordered,
attach them by placing them onto their
corresponding building block style recesses
on the footplate (a & b). Put the sandal on
top and secure with the sandal bolt (as per
section 7.4).
A
7.10 Attaching the hip belt
bracket
Before you can attach the de-rotation hip
belt you will first of all need to attach the hip
belt bracket. To do this slide the bracket into
the receiving slots in the hip pad metalwork
(a) and secure using the Allen bolt and
washer provided (b). Repeat this on the
other side. The de-rotation hip belt does not
require hip laterals.
B
A
B
