6 AFTER TEST

1 Release all pressure from the adhesion gauge.
2 Detach the adhesion gauge or actuator from the dolly adaptor.
3 Press the "MAX" softkey to release the 'Max Hold'.

7 DOLLY ADAPTORS

Dolly adaptors are available for testing Elcometer 106 , 506 and 510
pull-off adhesion gauges. Adaptors are also available for testing other
manufacturers' gauges.
Description
Elcometer 506 / 510 Dolly Adaptor:
20 & 14.2mm Skirts
Elcometer 506 / 510 Dolly Adaptor:
50mm Skirt
Elcometer 106 Dolly Adaptor: Scales 1 to 4
Elcometer 106 Dolly Adaptor: Scale 6
AT-M & AT-A Adhesion Gauge Dolly Adaptor
PAT Adhesion Gauge Dolly Adaptor

8 WARRANTY STATEMENT

The Elcometer AVU is supplied with a 12 month warranty against
manufacturing defects, excluding contamination and wear.

9 TECHNICAL SPECIFICATION

Range
Resolution
Accuracy
Power
Supply

Dimensions

Weight

Note: Batteries must be disposed of carefully to avoid environmental contamination.
Please consult your local Environmental Authority for information on disposal in
your region. Do not dispose of any batteries in fire.
b
The Elcometer AVU is not suitable for verifying the accuracy of the Elcometer 106 Scale 5 due to its scale
range.
www.elcometer.com
b
0 - 30MPa (0 - 4000psi)
±0.01MPa (1psi)
±0.33% of full scale
2 x AA alkaline dry batteries
(rechargeable batteries can be used)

165 x 155 x 105mm (6.5 x 6.1 x 4.1")

3kg (6.6lbs)

b
Part Number
T99923935
T99923936
b
T99923937
T99923938
T99923939
T99923986
R
en-6
