ZAPTEC Pro Bedienungsanleitung Seite 13

Colour Meaning
NO LIGHT Charging station has not been activated in the ZAPTEC Portal, no power from the
power circuit, incorrect connection or product fault. Check the serial protection in
the distribution cabinet.
Not updated during charging.
PURPLE
• Check that the charging cable has been inserted into the charging station
GREEN
correctly.
• Check that the vehicle has been configured to start charging immediately.
• Communication is taking place between the charging station and the vehicle.
BLUE
• Check whether the vehicle is configured to start charging immediately.
Flashing red light
RED
• Authentication failed – Check that the RFID tag/charging card is connected to
your user profile.
• Authentication failed – Check in the ZAPTEC Portal that your user has access to
charge on the charging station and/or installation concerned.
Steady red light
• Disconnect the charging cable. If the status indicator illuminates green, you can
connect the charging cable again. If charging does not start and the indicator
illuminates red again, there may be a charging fault on the charging cable or
vehicle.
• If the status indicator lamp does not turn green after the charging cable has been
disconnected, you must check the fuses as described in the chapter 'Checking
the fuses in the charging station'.
• Authentication failed – Check that the RFID tag/charging card is connected to
your user profile.
If the charging station has been disconnected from the power network, it will take 2–3 minutes
i
before the charging station starts up again.
Serial number
e.g. ZPR123456
