Specifications
Specifications
Specifications
Specifications
Specifications
Platform
- ATX Form Factor: 12.0-in x 7.8-in, 30.5 cm x 19.8 cm
CPU
- Support for Socket AM3 processors: AMD Phenom
X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron
processors
- Six-Core CPU Ready
- Supports UCC feature (Unlock CPU Core) (see CAUTION 1)
- Supports AMD's Cool 'n' Quiet
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology (see CAUTION 2)
- Supports Hyper-Transport Technology
Chipset
- Northbridge: AMD 480X CrossFire
- Southbridge: AMD SB600
Memory
- Dual Channel DDR3 Memory Technology (see CAUTION 3)
- 4 x DDR3 DIMM slots
- Support DDR3 1800(OC)/1600/1333/1066/800 non-ECC,
un-buffered memory (see CAUTION 4)
- Max. capacity of system memory: 16GB (see CAUTION 5)
Expansion Slot
- 1 x PCI Express x16 slot
- 2 x PCI Express x1 slots
- 3 x PCI slots
Audio
- 5.1 CH HD Audio (VIA
LAN
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
Rear Panel I/O
ASRock HD 6CH I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x Parallel Port (ECP/EPP Support)
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in/Front Speaker/Microphone
Connector
- 4 x Serial ATAII 3.0Gb/s connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and "Hot Plug" functions
(see CAUTION 6)
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- CPU/Chassis/Power FAN connector
ASRock
manuals search engine
TM
Technology
TM
Chipset
®
VT1705 Audio Codec)
M3A UCC
Motherboard
TM
II X4 /
5 5 5 5 5
