1.2 Specifications

Platform
CPU
Chipset
Memory
Expansion
Slot
Graphics
8
• Mini-ITX Form Factor
• 10 Layer PCB
th
• Supports 12 Gen Intel® Core
• Digi Power design
• 11 Power Phase design
• Supports Intel® Hybrid Technology
• Supports Intel® Turbo Boost Max 3.0 Technology
• Intel® Z690
• Dual Channel DDR5 Memory Technology
• 2 x DDR5 DIMM Slots
• Supports DDR5 non-ECC, un-buffered memory up to
6400+(OC)*
* Supports DDR5 4800 (1DPC) natively.
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
• Max. capacity of system memory: 64GB
• Supports Intel® Extreme Memory Profile (XMP) 3.0
• 15μ Gold Contact in DIMM Slots
• 1 x PCIe Gen5x16 Slot*
* Supports PCIe riser cards to extend one x16 slot to two x8 slots
* Supports NVMe SSD as boot disks
• 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT
PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT)
• 15μ Gold Contact in VGA PCIe Slot (PCIE1)
• Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
e
• Intel® X Graphics Architecture (Gen 12)
• Three graphics output options: HDMI, DisplayPort 1.4 and
TM
Intel® Thunderbolt
• Supports Triple Monitor
• Supports Intel® Thunderbolt
8K (7680x4320) @ 60Hz*
TM
Processors (LGA1700)
4 ports
TM
4 with max. resolution up to
