List of spare parts CLEAR 2.0 RD ¾" - 1¼"
Item Designation (Recommended average replacement interval
for wearing parts [*])
Wearing parts set "Pressure reducer cartridge"
A
(consisting of items 2, 3, 4)
Wearing parts set "Screen, suction pipe and gasket"
B
(consisting of items 9, 12, 13)
Wearing parts set "Flushing valve and gaskets"
--
(consisting of items 9, 14, 22)
D Spare parts set "Manometer"
Spare parts set "Handwheel for backwashing"
E
(consisting of items 18, 19, 20, 21, 23, 24, 25)
1 Cylinder screw M6×130 (set with 4 pcs)
2 Pressure reducer cartridge
3 O-ring 52×3.5
4 O-ring 25×3.5
5 Noise screen
6 Front cover, complete
7 Backflow preventer
8 Basic housing
9 Profiled flange gasket
10 Rear cover
11 Pan washer head screw 4×10
12 Screen
13 Suction pipe
14 Flushing valve
15 Suction pipe base
16 Filter bowl + items 9, 15, 17
17 Flange
18 Cover filter bowl
19 Pan head screw 3.9×13
20 Spacer disc
21 Retainer
22 O-ring 6.07×1.3
23 Hose connection piece + item 22
24 Union nut
Piece(s) Order no.
**** 1 2990251
**** 1 2990411
**** 1 2170561
1 2170483
1 2990247
1 2060462
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1 2170439
1
1
2
1
1
1
1 2170182
1
