Camera Overview; English - Concord Eye-Q 3042AF Schnellstartanleitung

This Quick Start Guide provides a quick reference for operating your
new digital camera. Refer to the User's Guide, which can be found on
the CD-ROM and a hard copy in your Concord Eye-Q 3042AF box, for
detailed instructions on how to use all of your camera's features. Before
using the camera, make sure to read all safety instructions and
precautions outlined in the User's Guide.

CAMERA OVERVIEW

Top/Front
1
2
3
4
11. Flash Ready LED
12. Viewfinder
13. Auto-Focus LED
14. LCD
15. Tripod Socket
16. Battery/Memory
Card Door
17. Mode Switch
18. Navigation Arrow
buttons/Zoom
buttons/Flash button
A
QUICK START GUIDE
19. OK button/
Enlargement button
20. Reset Button
21. MENU Button
22. Wrist Strap Holder
23. LCD On/Off Button
24. Memory Card Slot
25. Battery
Compartment
003/016
5
1. Power Button
2. Shutter Button
6
3. Flash
7
4. Lens
5. Viewfinder
8
6. Flash Sensor
9
10
Bottom/Back
11
12
13
14
15
16
1
A

ENGLISH

7. Red-eye Reduction
LED/Self-Timer LED
8. Mini-USB port
9. Video/TV-Out port
10. Macro Mode Switch
17
18
19
20
21
22
23
24
25
