The Camera

Overview of your Concord Eye-Q™ Duo Camera
FRONT/TOP
1
2
8. Camera Ready LED
9. Cable Connection Panel
10. Menu Button
11. Tripod Socket
12. Power Button
13. Status LCD
14. Select Button
15. Battery Door
STATUS LCD
A
B
C
D
E
Downloaded from www.Manualslib.com manuals search engine
3
1. Shutter Button
4
2. Lug for Neck / Wrist Strap
5
3. Viewfinder
4. Self-timer LED
6
5. Flash
7
6. Ir Filter and Lens
7. Interchangeable Face Plate
BACK
8
9
10
11
A. Self-timer
F
B. Flash
C. Memory Usage
D. Photo Quality
G
E. TV Mode
F. Delete
H
G. Photo Counter
H. Battery
I
I. Live Mode
6
12
13
14
