LOADING THE BATTERIES

The Concord Eye-Q™ Duo uses 2 alkaline AA batteries.
To load the batteries:
1. Locate the battery cover on the bottom of the camera.
2. Slide the button on the battery cover toward the center of the camera.
(fig.1)
3. Lift the cover to open.
4. Insert the batteries with the positive terminal toward the + sign, and the
negative terminal toward the - sign. (fig.1.1)
5. Close the cover.

TURNING THE CAMERA ON AND OFF

To extend battery life, the camera automatically powers off after 30 seconds of inactivity.
When the camera is turned on, the camera ready LED on the back of the camera blinks and the
Status LCD displays the current settings.
1. Press the Power button.
2. The camera is ready for picture taking when the camera ready LED stops
blinking and LCD icons appear on the Status LCD.
3. To turn the camera off, press the Power button.

SETTING THE FLASH

The Concord Eye-Q™ Duo has two flash modes, Automatic Flash and Flash Off. The current Flash
setting is displayed in the upper left hand corner of the Status LCD. If the Flash Icon is not present,
the camera is in Flash Off mode.
Setting the Flash Mode:
1. Press the Menu button until the Flash icon is activated.
2. Press the Select button to toggle between Automatic Flash and Flash Off.
The flash icon will blink to indicate Flash Off and remains steady to
indicate Automatic Flash.
3. When the setting you desire appears on the Status LCD, wait 5 seconds
for the camera to return to picture taking mode or scroll through the
options using the Menu button until a number appears in the photo
counter.
Note: The flash may need time to recharge between photos. While it is charging the Flash icon
on the Status LCD flashes and the camera ready LED blinks. When both stop blinking, you are
ready to take another picture.
Downloaded from www.Manualslib.com manuals search engine
2
fig.1
fig.1.1
