Technical Data

)
Environmental conditions
In operation
Temperature 10 to 40 °C (50 to 104 °F)
Atmospheric pressure 800 to 1100 hPa
(11.6 to 15.9 psi)
Rel. humidity 5 to 95 %, no dew
In storage and transit
Temperature –40 to 70 °C
(–40 to 158 °F)
Atmospheric pressure 115 to 1100 hPa
(1.6 to 15.9 psi)
Rel. humidity 5 % to 95 %, no dew
Flow settings 0, 1, 2, 3, 4, 6, 8, 12,
15 L/min
Accuracy ±0.5 L/min or ±10 %,
(at 4.5 +0.2 bar) whichever is greater
Delivery pressure 4.5 +0.2 bar
(4500 +200 cmH
Weight 420 g
Gas inlet DIN O
2
Gas outlet 6 mm nozzle
Thread 9/16"
Housing material Nickel-coated brass
Classification Class II a
as per EC Directive
93/42/EEC Annex IX
UMDNS Code 14-325
Universal Medical Device
Nomenclature System –
Nomenclature for medical
devices
Instructions for Use Compact flowmeter
* 1 bar = 1 kPa x 100
Dimensions (mm)
90
40
*
O)
2
connector
English / English US

Order List

Designation
Compact flowmeter with 6 mm nozzle
Compact flowmeter with
9/16" connection
Accessories
Mask (set of 50)
Mask with reservoir (set of 50)
Adapter 9/16" on 6 mm nozzle
O nasal cannula 2.1 m (set of 50)
2
Part No.
2M86793
MP01204
MX30101
MX30108
MP00416
5730354
