1. Description

The EX-1510HMVS is a plug & play high-speed USB 3.2 (Gen1) managed metal hub
for 10 USB devices. The EX-1510HMVS provides 10 ports for USB devices and 1 up-
link port for PC. It supports all USB connections from 1.1 to 3.2. All ports can fix with
screw lock. Via a external power supply it is possible to provide a maximum of 2,4A on
each USB port. With the management software, it is possible to control the hub remote-
ly. For example, you can easily turn the downstream ports on and off individually or
collectively, remotely restart the hub, reset it to factory defaults and assign a password
to prevent unauthorized access via the software. The EX-1510HMVS also has a flash
memory that allows you to save your settings. The EX-1510HMVS design fully utilize
the Genesys chipset, which represents the latest in SuperSpeed USB interface technol-
ogy. It uses data transfer rates up to 5Gbit/s. It provides a secure and very high data
transfer on each single port. The EX-1510HMVS support only the Self Powered mode.
In addition the EX-1510HMVS is equipped with an 15KV ESD surge protection. The EX
-1510HMVS is IP30 compliant. The DIN-Rail Kit is included in the extent of delivery for
installation in a 19" Rack. The DIN-Rail kit will be tightened with two screws on the back
of the EX-1510HMVS.
Features:
•
Compatible for USB 1.1, 2.0, 3.0 & 3.1
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1510HMVS to your PC, you should first check the contents
of the delivery:
•
EX-1510HMVS
•
USB 3.2 (Gen1) Cable (screw lock)
•
2x DIN-Rail Kit (EX-6096)
•
Driver CD
•
Manual
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
