Technical Specifications - Siemens SIMATIC HMI KTP700F Mobile Arctic Produktinformation

Technical specifications

Dimension drawing KTP700F Mobile Arctic
Certificates and approvals
Approvals
The device is certified as shown on the rear of the device.
Technical specifications
This section contains the technical specifications of the KTP700F Mobile Arctic, which differ from the technical specifications
of the KTP700F Mobile. You can find all other specifications in the "Mobile Panels 2nd Generation" operating instructions.
Display
Type
Active display area
Display diagonal
Resolution
Number of colors
Brightness control
Backlighting
Half Brightness Life Time (MTBF
Pixel error class in accordance with EN ISO 9241-307
Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is
1
increased by using the integrated dimming function, for example, time-controlled via screen saver or centrally via
PROFIenergy.
KTP700F Mobile Arctic
A5E49199858-AA, 02/2020
)
1
All dimensions in mm
KTP700F Mobile Arctic
LCD TFT
152 mm x 91 mm
7.0"
800 × 480 pixels, widescreen
Up to 16 million
By software
LED
50000 h
I
13
