DMX operation

Setting the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 12 control channels.
However, it can also be switched to a mode with 10 channels if different functions are required. To be able to
operate the device with a DMX controller, the DMX starting address must be set. The starting address
depends upon which DMX controller is being used. Please refer to the controller's documentation.
1 Press the MENU button so many times until Addr is indicated on the display. Confirm with the ENTER
button.
2 Now the display calls up the menu item for the DMX starting address: A001.
3 Use the buttons UP and DOWN to set the address. Confirm with the ENTER button.
4 In order to choose the desired DMX channel mode, press the MENU button so many times until CHnd is
indicated on the display. Confirm with the ENTER button.
5 The display indicates 10 CH (10 DMX channels) or 12 CH (12 DMX channels). Use the buttons UP and
DOWN to select the desired DMX channel mode. Confirm with the ENTER button
6 A dot will flash when DMX signals are being received.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.

Functions in DMX mode

Mode / Channel
10 CH 12 CH
1 1
0
2
0
2 3
0
4
0
3 5
0
0
5
10
15
4 6
20
25
30
35
40
45
Value
Horizontal movement (PAN)
Push slider up in order to move the head horizontally (PAN). Gradual
255
head adjustment from one end of the slider to the other (0-255, 128-
center). The head can be stopped at any position you wish.
PAN-movement with 16-bit resolution
255 Fine indexing
Vertical movement (TILT)
Push slider up in order to move the head vertically (TILT). Gradual
255
head adjustment from one end of the slider to the other (0-255, 128-
center). The head can be stopped at any position you wish.
TILT-movement with 16-bit resolution
255
Fine indexing
PAN/TILT speed
255 Decreasing speed
Color-wheel
4 Open/White
9 White + Red
14 Red
19 Red + Green
24 Green
29 Green + Blue
34 Blue
39 Blue + Yellow
44 Yellow
49 Yellow + Light blue
Feature
