6 Parts and spare parts list
Nr. Artikelnr.
1
2
3 580043CW
4 580042
5 580044
6 580045A
n. Img. 580047A-07-24
n. Img. 990062-K
n. Img. 560519PP
n. Img.
n. Img.
The numbers refer to the illustration on page 10.
Beschreibung
- Trigger
- Valve Body
Spring
Flow Adjustment Screw
Pivot Pin
Pinch Tube Assembly, ca. 11 cm, Ø 2,5 mm
Pinch Tube Assembly, ca. 60 cm, Ø 1,8 mm
Dispensing Tip Set small
Luer-Lock Adapter
- Allen Key 3/32"
- Allen Key 1/16"
