VIEWEG
5 Material Supply
1. Thread the luer lock adapter onto your cartridge reservoir with ¼" NPT port.
Assemble the reservoir into the appropriate retainer and cap. Twist lock the female
EN
end of the supply hose onto the adapter and connect the male end onto the inlet
side of the DV-5110 Pen.
2. Hold the PEN in your hand as if you were writing. Depress the ON/OFF lever and
open the supply reservoir to feed the PEN. As soon as all air has been purged from
the supply hose and pinch tube assembly, release the ON/OFF lever to stop flow.
Attach the desired needle tip.
3. To fine-tune the flow control or dot size desired, use the included allen wrench to
adjust the stroke of the ON/OFF lever. This adjustment is on the underside of the
PEN body, opposite the lever.
4. With repeated use, a closely controlled application can be achieved with the
availability of adjusting the following:
A. Pressure on the supply reservoir
B. Needle tip size
C. Stroke adjustment on the ON/OFF lever
Operating Manual DV-5110
12
