3 Assembly
The DV-5110 Pen is supplied as a pre-assembled applicator.
In addition, spare pinch tube assemblies and dispensing needle tips, a supply hose and
EN
¼" NPT adapter are included.
1
2
4
3
1 Trigger
2 Spring
3 Valve Body
4 Flow Adjust Screw
Operating Manual DV-5110
5
Pivot pin
6
Pinch Tube Assembly
7
Pinch Cushion
10
5
6
7
