Model assembly

Main wing and auxiliary fuel tanks installation
1.Slide the auxiliary fuel tanks into the rails as shown.
2.Using the three included Y-harnesses, connect the
two retract leads, two aileron leads and two flap leads.
Insert all leads on the wing into the fuselage via the
fuselage passthrough. Attach the wing onto the fuse-
lage and ensure that the wires do not interfere with any
of the servos.
Horizontal stabilizer installation
1.Slide the horizontal stabilizer spar into the slot near the
rear of the fuselage.
2.Install the two pieces (left and right) horizontal stabilizer
as shown. Ensure the control horn faces down.
3.Secure the wing to the fuselage with included screws
as shown. Do not over tighten the screws.
3.Secure the two horizontal tail pieces in place using
the included screws.
HKM3.0*32mm
KA2.6*12mm
