OPERATING INSTRUCTIONS

The air sucked by the fan enters from the grill and
passes through the filter, then it is cooled/dehumidified
or heated through the heat exchanger.
The direction of the air outlet is motorized up and down
by flaps, and manually moved right and left by the vertical
deflectors, for some models, the vertical deflectors could be
controlled by motor as well.
"SWING" CONTROL OF THE AIR FLOW
The air outlet flow is uniformly dist-
SWING
ributed in the room.
It is possible to position the direction
of the air in the optimal.
The key
the air flow is directed alternatively from
up to down .In order to guarantee an even
diffusion of the air in the room.
The key activates the motorized deflectors ,
SWING
the air flow is directed alternatively from left to right.
(Optional function, depends on the models)
In cooling mode , orient the flaps in horizontal
direction;
In heating mode, orient the flaps downward as
the warm air tends to rise.
The deflectors are positioned manually and placed un-
der the flaps .They allow to direct the air flow rightw-
ard or leftward.
This adjustment must be done while the appliance
is switched off.
Never position Flaps manually, the delicate mech-
anism might seriously damaged!
Never poke fingers, sticks or other objects in the air
inlet or outlet vents. Such accidental contact with live
pants might cause unforeseeable damage or hurt.
or activates the FLAP ,
SWING
SWING
Heat
Exchanger
MODE
FAN
SWING
HEALTH
flap
movement
