2.4 Expansion Slots (PCI and PCI Express Slots)
There are 2 PCI slots and 4 PCI Express slots on this motherboard.
PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI
interface.
PCIE slots:
PCIE1 / PCIE2 / PCIE4 (PCIE 2.0 x1 slot) is used for PCI Express cards
with x1 lane width cards, such as Gigabit LAN card, SATA2 card, etc.
PCIE3 (PCIE 3.0 x16 slot) is used for PCI Express x16 lane width
graphics cards.
Only PCIE3 slot supports up to Gen 3 speed. To run the PCI Express in Gen
3 speed, please must install the Ivy Bridge CPU. If you install the Sandy
Bridge CPU, the PCI Express will run only at PCI Express Gen 2 speed.

Installing an expansion card

Step 1. Before installing the expansion card, please make sure that the power
supply is switched off or the power cord is unplugged. Please read the
documentation of the expansion card and make necessary hardware
settings for the card before you start the installation.
Step 2. Remove the system unit cover (if your motherboard is already installed
in a chassis).
Step 3. Remove the bracket facing the slot that you intend to use. Keep the
screws for later use.
Step 4. Align the card connector with the slot and press fi rmly until the card is
completely seated on the slot.
Step 5. Fasten the card to the chassis with screws.
Step 6. Replace the system cover.
