Motherboard Layout
USB 3.0
T: USB2
B: USB3
USB 2.0
T: USB4
B: USB5
35
34
33
32
31
30
29
1 CPU Fan Connector (CPU_FAN1)
2 1155-Pin CPU Socket
3 ATX 12V Power Connector (ATX12V1)
4 Power Fan Connector (PWR_FAN1)
5 2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A1, DDR3_B1, Black)
6 2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A2, DDR3_B2, Black)
7 SATA2 Connector (SATA2_5, Black)
8 SATA2 Connector (SATA2_3, Black)
9 SATA3 Connector (SATA3_1, Gray)
10 ATX Power Connector (ATXPWR1)
11 SATA3 Connector (SATA3_0, Gray)
12 SATA2 Connector (SATA2_2, Black)
13 SATA2 Connector (SATA2_4, Black)
14 Intel Z68 Chipset
15 64Mb SPI Flash
16 Chassis Fan Connector (CHA_FAN2)
17 Chassis Speaker Header (SPEAKER 1, Black) 34
18 System Panel Header (PANEL1, Black)
2
1 2 3
19.1cm (7.5 in)
USB 2.0
T: USB0
B: USB1 CPU_FAN1
ATX12V1
Top:
RJ-45
USB 3.0
CPU_FAN2
CHA_FAN1
LAN
PHY
PCIE1
SATA2_5
X
Fast LAN
CMOS
PCIE2 SATA2_4
Battery RoHS
PCIE3
Z68 Pro3 Gen3
PCI Express 3.0
PCIE4
PCI1
AUDIO
CODEC
X
Fast USB
PCI2
USB10_11
COM1
HD_AUDIO1 IR1
USB8_9 USB6_7
HDMI_SPDIF1
1
1
CLRCMOS1 1
1
1 1 1 1
CIR1
28 27 26 25 24 23 22 21 20
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
35
ASRock Z68 Pro3 Gen3 Motherboard
4 5 6
PWR_FAN1
7
8
9
SATA2_3
SATA3_1
10
SATA2_2 SATA3_0
11
12
13
SATA3 6Gb/s
Intel
14
Z68
64Mb 15
PLED1
1
BIOS
PANEL1
PLED PWRBTN CHA_FAN2
16
SPEAKER1
1
1
HDLED RESET
19 18 17
Power LED Header (PLED1)
USB 2.0 Header (USB6_7, Black)
USB 2.0 Header (USB8_9, Black)
USB 2.0 Header (USB10_11, Black)
Consumer Infrared Module Header
(CIR1, Gray)
Infrared Module Header (IR1)
Clear CMOS Jumper (CLRCMOS1)
COM Port Header (COM1)
HDMI_SPDIF Header
(HDMI_SPDIF1, Black)
Front Panel Audio Header
(HD_AUDIO1, Black)
PCI Slots (PCI1-2)
PCI Express 2.0 x1 Slot (PCIE4, Black)
PCI Express 3.0 x16 Slot (PCIE3, Black)
PCI Express 2.0 x1 Slot (PCIE2, Black)
PCI Express 2.0 x1 Slot (PCIE1, Black)
CPU Fan Connector (CPU_FAN2)
Chassis Fan Connector (CHA_FAN1)
