17 Technical Information

Water Cooling Kit Installation

Water Cooling Kit Installation

Two types of water cooling kits are available to be mounted when the
pump is used under heavy load conditions or when air cooling is
insufficient.
The two model part numbers are: 969-9823 (metallic model), and
969-9824 (plastic model).
Figure 23
The items of the plastic model kit must be assembled as shown in the following
CAUTION!
figure
Figure 24
210/228 Turbo-V 81-T User Manual / 87-900-984-01 (E)
