lamber DSP26-add Installation Bedienung Seite 21

The cycle will start for 2 minutes, including, besides the
washing, a five seconds stop and the rinsing of 18
seconds (23 seconds for machines with Water
softener) with clean water at 85°-90°C will start.
Once the cycle has ended, the lamp "F" restarts
blinking.
5
-
At the end of the cycle open the door and pull
out the basket.
NOTE. STOP CYCLE function: the washing cycle can
be stopped if you push again the cycle pushbutton "B"
(light "C" flashing now) :
to restarting washing cycl push again button "B".
WARNING! Do not open the dishwasher door
durino the washing cycle.
Manuel self-cleaning cycle:
- Ensure that the tank is empty,
- Make sure that the machine is switched off
- Remove the overflowpipe from the tank
- Close the door of the diswasher
- Press button "A" to switch the machine on
- Self-cleaning cycle starts, you can stop it after 5
minutes, otherwise
automatically turn off after 10 minutes. (for Machine
with drain pump the tank fills with water and stops
when maximum level is reached: empty the tank
manually and repeat the operation if needed).
In case of accidental opening the cycle stops. If You
close the door, the cycle starts again from the point
where it had stopped.
At the end of the cycle open the door and pull out the
basket.
ACHIEVEMENTS
Any deficiency in the washing process is apparent
when dirty residuals are visible. Any halos might be
caused by an insuffucuent rinsing: in this case, check
that the rinsing jets are clean and there is a sufficient
pressure in the water distribution network.
In the case that residuals are present, check that:
• the washing jets are clean
• there is detergent
• the pump suction filter is clean
• the positions of the objects in the rack are correct.
SALT CONTROL
(for machines with Water softener)
If the glass-washer is equipped with a Water softener
the regeneration of resins is automatic according to
parameters fixed by the producer.
According to the water hardness, it is possibile to
modify the programming of the regeneration.
N.B. each 90 seconds
duration, the machine stops for about 2
minutes to carry out the regeneration.
See the corresponding table in the installer section.
self-cleaning cycle
of tank filling
When it is necessary to add salt in the container, the
green lamp "H" lights up.
Unscrew the plug of the salt container at the bottom of
the tank and put 1 kg coarse salt tablets in it. Clean the
gasket and screw the plug.
Attention!
The lack of salt in the container damages the machine
because of limestone, besides a defective washing of
glasses and dishes.
These damages are not covered by the warranty.
DISHES POSITIONING
It is suitable to place dishes, inside the plastic
basket with the concave side facing upwards.
Place mixed cutlery in a vertical position into the
suitable container minding not to cram them and
whit handgrips towards the bottom (see draw).
will
It is suitable to place glasses, inside the plastic
basket with the concave side towards the
bottom. Place mixed cutlery in a vertical position
into the suitable container minding not to cram
them and with hafts towards the bottom (see
draw).
RINSING ADDITIVES
To grant a perfect rinsing, a quick drying and to
avoid calcareous sediments on glasses and
cups you must add a surfactant on water
(Brightener).
Your cleansing agent supplier will be able to
suggest the
machine is equipped with a rinse aid dispenser.
Mean concentration used is 0,15 g/lt.
DRAIN PUMP INSTRUCTION
(only for machines with drain pump)
The drain pump automatically starts up at each
cycle to discharge the exceeding water coming from
the rinsing cycle.
21
most suitable product. Your
