CEREC 3
Legend
DV DECT supply
F2 Fuse for +12V display
F4 Fuse for +5V STDBY key board
F Fan
FG Image processing board
H Lamp
HP1 Heater board for CEREC
camera
HP2 Heater board for SIROCAM 2
camera
IOR Camera PCB
KB Video board
D1 LED, camera status
NSB Video-PCB for power pack
F1 Fuse for lamp
F2 Fuse for camera electronics
V7 LED, supply voltage +12V
V8 LED, supply voltage +5V
V9 LED, supply voltage +12V lamp voltage
PC PC complete
SC3 SIROCAM 3 module
SE Plug element with voltage
selector
TT Key board
T/T1/2 Transformer
XAB IOBoard, analog data acquisition
and CCD activation
V19 - V25LED, CCD activation with readiness for
exposure
V36 LED, ACTIVE signal
V37 LED, option
V43 LED, reset following error in power supply
XAB D Board, digital data storage and
activation of the PC network
V900RD LED, Transmit
V900GN LED, Receive
V901RD LED, Link (address identification)
V901GN LED, 100Mbps (Megabits per second)
S1 Coding switch
58 35 710
S1
FS
S7
F1/F2
L2, L3, . Leads
L/R
Switches
Main switch
Foot switch
Thermoswitch
Other Components
Main fuses
Loudspeakers
Ferrite cores
Insulation
Protective ground wire
EMC ground
Blatt
6A
Sheet
Feuille
Hoja
Foglio
