Control name
J5 IN-OUT
J6 SERIAL
STATUS
P3 VENT
GAUGE
ON-OFF switch (not
shown in the picture)
TPS-compact User Manual / 87-901-010-01 (H)
Description of the TPS-Compact
Description
Input-output connector to remote control the TPS-compact
Serial input-output connector to control the TPS-compact via
an RS 232 or RS 485 connection
Blue LED to show the system operating condition
Connector to control the optional vent valve
Connector to control external FRG700
It is located on the rear side of the system. It is the power
supply switch.
