EB Models Packaging solution
Chiller supplied on a wooden
EB 30 – 43 – 60 WT
EB 75 – 90 WT
pallet and protected by
EB 130 – 150 WT
a cardboard box
Chiller supplied on a wooden
EB 190 – 250 WT
pallet and wrapped
EB 300 – 350 – 400 WT
with protective film
Note!
The above mentioned packages are not suitable for piling up units on top of each other
Store the Chiller in a dry place, away from heat sources. All waste materials should be recycled in the appropriate
manner.
For the operations of lifting and movement it is necessary to use a fork lift truck with proper load capacity and with forks
longer than the base of the Chiller. Avoid sudden movements which can damage the framework and the internal
components. PFANNENBERG Std Chiller (above 45Kg weight) are also provided with 4 eye bolts for lifting and
transportation; to be used for vertical loading/unloading only (to see the right point for lifting please refer to the stickers
on the unit).
Check after the final positioning of the Chiller the internal connections to avoid damage during operation.
CAUTION:
take care to the operations of lifting and movement. The chillers ( especially for AR series ) are
heavy and tall. There is the risk of overturning when the unit is moved with a fork lift.
English
Picture 1 – Chiller lifting
