Supplementary instructions
Dosing monitor Flow control 1, 2 and 3,
for suction side installation
These supplementary operating instructions are only valid with the corresponding
"Operating instructions for ProMinent Flow Control dosing monitor"!
The information in these supplementary instructions replaces the information in the
corresponding operating instructions.
Flow Control
Size 1
Size 2
Size 3
About the Product
The Flow Control for suction side installation is suitable for the
®
delta
solenoid metering pumps, when these have been setup with
a slow discharge stroke. The discharge strokes are detected on the
suction side, because here the flow velocity is sufficiently high.
Hydraulic Installation
Screw the Flow Control directly onto the pump suction valve
(indicates adjustment knob to operator?)
Type overview
for delta type
1608 - 1612
1608 - 0730
0450 - 0280
Adjustment
(All figures refer to water at 20 °C)
Stroke length, minimum values: 30 %
Possible values in "Settings" - "Dosing" - "Settings"
(suction stroke):
Normal
HV1
HV2
www.prominent.com
Material type
PVDF / EPDM
PVDF / FPM
PVDF / EPDM
PVDF / FPM
PVDF / EPDM
PVDF / FPM
Part no.
1036441
1036444
1036407
1036409
1036439
1036440
BA MAZ 033 10/10 DE/EN/ER/ES
