LED indication on "Power ON /OFF "Key
System Status
System power on
System power off
System over/under temperature
System UPS Battery is charging
System thermal sensor faulty
System UPS Battery Capacity Low
System is powered by UPS battery
only
LED indication on "Touch ON/OFF "Key
Touch Status
Touch function ON
Touch function OFF
LED indication on "SHIFT "Key
System Status
System switch to S1/S2/S3/S4/S5/S6
System switch to S7/S8/S9/S10/S11/S12
4 / 16 Quick Start Guide DLT-V4108, V01
DLT-V4108 Industrial PC
LED Status
Static
Off
Static
Static
Blinking 0.5 sec. on / 0.5 sec. off
Blinking 0.2 sec. on / 0.8 sec. off
Blinking 0.5 sec. on / 0.5 sec. off
LED Status
Off
Static
LED Status
Off
Static
PN:2005410870
Quick Start Guide
Color
Green
x
Red
Orange
Red
Orange
Green
Color
x
Orange
Color
x
Orange
