7.6
Connecting the USB, Ethernet, COM cables, and optional HD Adapter Cable
NOTICE: Physical damage
Only use accessories that have been tested and approved by Advantech-DLoG for DLT-V4108.
Proceed as described with the power supply cable:
Insert the cable.
Attach matching cable grommet.
Insert in the cable pass-through.
Secure to the strain relief rail using cable clip and screws.
Detail view adapter cable for the optional Harness Cable
12 / 16
Quick Start Guide DLT-V4108, V01
Quick Start Guide
DLT-V4108 Industrial PC
PN:2005410870
