Quick Start Guide
DLT-V4108 Industrial PC
7.5
Securing the power supply cable to the strain relief rail
 Place one cable clip on the power supply cable.
 Secure the cable clip to the strain relief rail using 2 mounting screws (M3x10 screws included in
accessory box).
 Tighten the mounting screws alternatingly.
 ATTENTION: Tighten the mounting screws sufficiently but on no account pinch or crush the cable.
If you do, the cables may break or the cable insulation may be damaged.
Advantech-DLoG
Quick Start Guide DLT-V4108, V01 PN:2005410870
11 / 16
