7.4 Securing the ground using ring tongue to the ground bolt
Secure the ring tongue of the power supply cable to the ground bolt:
10 / 16 Quick Start Guide DLT-V4108, V01
 ATTENTION
To make sure the device is grounded correctly, it is
important to follow the correct order of components
on the ground bolt as below (from inside to outside):
1
2
3
Quick Start Guide
DLT-V4108 Industrial PC
1. Place "toothed washer" first (internal)
2. Then put the "Ring Tongue of the power
supply cable" (flat side faces DLT-V4108
connector panel)
3. Tighten the nut hand-tight.
PN:2005410870 Advantech-DLoG
