Listing Of Replacement Parts - WALTHER PILOT PILOT Misch-Automatik Betriebsanleitung

Listing of Replacement Parts:

Item Description
1 Air head nut
2 Air Head *
3 Air head seal
4 Material nozzle *
5 Gun body compl.
6 Piston compl.
7 Needle chuck
8 Needle chuck
9 Cap
10 Material Needle compl.
11 Needle Spring
12 Spring bushing
13 Counter-screw
14 Needle seal Packing comp.
15 Needle gland nut
16 O-Ring
17 Packing Screw
18 Air control valve compl.
19 Seal
20 Double Nipple
21 Cap nut
22 Hose grommet
23 Double Nipple
24 Cap nut
25 Hose grommet
26 Double Nipple
PILOT Misch-Automatik
V 24 340
piece Parts No
.
2 V 24 329 05 000
1 V 24 329 04 XXX
2 V 09 101 75 000
2 V 24 329 01 XXY
1 V 24 340 01 000
1 V 24 340 03 000
2 V 10 206 02 000
2 V 10 506 02 000
1 V 24 336 03 000
2 V 24 340 05 XX3
2 V 10 306 04 000
2 V 24 306 05 000
2 V 20 001 06 000
2 V 10 361 08 000
2 V 01 101 01 000
2 V 09 102 02 000
2 V 20 201 02 000
1 V 00 101 74 750
2 V 09 101 76 010
1 V 24 321 03 000
1 V 00 101 03 000
1 V 00 101 02 003
1 V 24 381 05 000
1 V 00 101 12 003
1 V 24 321 09 003
2 V 00 101 01 000
22
* Please quote the required size(s) when placing an order for replacement parts.
It is recommended to keep in stock all BOLD-faced parts (fast wearing parts).
Repair kit
A WALTHER repair kit is available for the spray gun PILOT Misch-Automatik which
comprises all wearing parts.
PILOT Misch-Automatik Standard-Version
Nozzle set
Nozzle set consist of air cap, material nozzle and material needle.
PILOT Misch-Automatik Standard-Version
Nozzle sizes optional:
▪ 0,5 ▪ 0,8 ▪ 1,0 ▪ 1,2 ▪ 1,5 ▪ 1,8 ▪ 2,0 ▪ 2,2 ▪ 2,5 mm ø (further sizes on request).
Parts-No.
V 16 243 40 XX3
Parts-No.
V 15 243 40 XX3
