DEVICE DESCRIPTION

1. Movable plate
2. Inner pot
3. Lid
4. Control panel
5. Steam valve
6. Handle
7. Base unit
8. Place for fi xation of rice scoop holder
9. Power plug
Accessories
10. Rice scoop
11. Soup scoop
12. Measuring cup
13. Steam bowl
14. Wire
15. Rice scoop holder
Control panel
NOTE
• The multi-cooker is equipped with a sensory control panel. To activate
buttons you only need to lightly touch them with your fi ngers. Do not press
the buttons with force. If the button is not activated after the touch you
simply need to increase the contact area.
• Never clean the control panel with solvents such as ethanol or acetone
so as not to damage the inscriptions and coating.
• Each stage of the program setup is accompanied by a short sound signal.
• If during the setup of the program, cooking time or timer no buttons are
touched for 10 seconds the multi-cooker starts producing short sounds un-
til one of the buttons is pressed.
1. Heating / Cancel
• Turning heating on/off. To heat a dish please push this button and the
multi-cooker will heat it up and maintain the temperature of 60-80°C.
During this the button is lit and the display shows the count-up timer.
• Setting cancellation. To cancel the current settings push and hold this
button for 3 seconds. This will put the multi-cooker in standby mode.
2. Level of cooking
• In "Rice" mode you can choose one of three levels of cooking (Soft,
Standard, Hard). When you press this button the cooking level indication
changes cyclically: Standard
3. Start
• Standby mode indication. When the multi-cooker is plugged into an elec-
tric outlet the start button light starts fl ashing.
• Program start. During the cooking process the light is on continuously.
Hard Soft.
