To enable the function to be switched off, the parallel
button position (5-B) should not be dei ned with another
function. This also applies if you want to be able to stop
ventilation functions Reduced and Forced before the
run-on time.
Defi ne a remote control function to a multi-button
• In the menu Advanced/Dei ne system , move to
line Remote control and press OK.
• Place the cursor in the line for the relevant remote
control function and press OK .
• Press the up arrow button until the SmartControl
channels are displayed.
• Enter the channel that was previously dei ned for
the button (see Dei ne SmartControl accessories )
and select position (A or B) for the desired remote
control function.
8.1.4 Defi ne room sensor
In order to be able to use a sensor in the SmartControl
series as a room sensor, it must be connected to the
current heating system.
• Go to menu Advanced/Dei ne system and select
Heating system 1 or Heating system 2.
• Select Yes in the line Room sensor .
• Select SmartControl in the line Type (press up
arrow button until SmartControl is displayed).
• Select the same channel (#1) on the menu line
Channel that was previously selected for this
room sensor (see section Dei ne SmartControl
accessories) .
8.2

Operation

This menu displays current temperatures and operating
data.
On the right hand side, the menu shows e.g. the
temperature for the connected room sensor.
If a ventilation unit and combined room sensor (for
measuring rH and Co ) have been installed, the
2
ventilation submenu can be used to display humidity
and carbon dioxide readings. Click on the i on the fan
symbol to reach this submenu.
Define system
<<
Heating circuit 1
Heating circuit 2
Heat pump
CTC SMS
Cooling
Solar panels
Diff thermostat function
Pool
DHW circulation
External heat source
Def heating circuit 1
Heating circuit 1
Room sensor 1
Type
Channel
Operation data system
Operation data EcoVent
Mode
Highest lev. rH
Highest lev. CO2
Night cooling
Days to service filter
English
No
No
No
No
No
Yes
Yes
SmartControl
1
EN
Reduced 20%
40
550
Off
89
13
