2. Room sensor

General

2.1
The wireless room sensor is powered by the integrated solar cells, which can
be supplemented by the supplied battery (1/2AA) if light levels are low.
The sensor is connected to the wireless network via the main product
display. This is described in menu chapter Touchscreen .
2.2

Installation

The room sensor should be placed in a suitable location in the home that is
representative of the temperature in the room, not in a draughty location or
near a heat source. If possible, position the sensor where the solar cells can
be charged by natural daylight.
• To remove the base plate, push in the latch at the bottom of the sensor
with a screwdriver.
• Use screws to attach the base plate of the sensor to a lat wall surface.
• Connect the sensor to the system using the software, see chapter First
start below.
• Push the cover onto the base plate.
2.3

First start

Connect/deine the room sensor to the wireless system by selecting a
vacant channel position in the Deine menu on the display and then pushing
the "learn button" on the sensor. For detailed information, see chapter
Touchscreen/ Deine SmartControl accessories .
To connect the sensor to the current heating system, see chapter
Touchscreen/Deine SmartControl accessories.
English
"Learn button": to connect
to/pair the sensor with
Gateway
Latch to remove base plate
