NO Spare parts
1 Top cover
2 Ambient temp. sensor
3 Ambient temp. sensor clip
4 Back grill
5 Evaporator
6 Coil temp. sensor
7 Temp. sensor clip
8 Sensor casing pipe
9 Distribution piping
10 Isolation panel
11 Reactor
12 Pillar
13 Upper frame
14 Fan motor bracket
15 Clip
16 Evaporator Heating Belt
17 Bracket for panel
18 Fan motor
19 Fan blade
20 DC motor casing tube
21 Controller box
22 Right panel
23 Ventilation grid
24 Front panel
25 Water proof box
26 Controller
27 N/A
28 N/A
29 Compressor
30 Anti-vibration hammer
31 Liquid reservoir
32 Compressor heating belt
33 Base tray
34 Handle
35 Terminal board
36 Right panel
37 Power supply 3-position terminal
38 Pressure gauge
NO Spare parts
39 Clip
40 Terminal board Bracket
41 Water pump 3-position terminal
42 Terminal cover
43 Rubber fixing block
44 Gas colleting piping
45 Back panel
46 Back gas piping
47 Low pressure switch
48 Pipe (4-way valve to Gas collect )
49 Exhaust pipe
50 Pipe (4-way valve to exchanger)
51 4-way valve
52 High pressure switch
53 Exhaust temp. sensor
54 Pipe ( Liquid reservoir to EEV )
55 Pipe ( Filter to Liquid reservoir )
56 Pipe (EEV to Distribution )
57 EEV
58 Filter
59 Pipe (Titanium exchanger to filter )
60 Water flow switch
61 Water outlet temp. sensor
62 Water outlet temp. sensor clip
63 Titanium heat exchanger
64 Water connection
65 Blue rubber ring
66 O' ring
67 Water inlet temp. sensor
68 Drainage plug
69 Red rubber ring
70 Sealing ring for water flow switch
71 PCB
72 N/A
73 Board
74 Electric box cover
75 Electric box
