Hydro-Pro INVERBOOST+ Tech Benutzer- Und Wartungshandbuch Seite 37

NO. Spare parts
1 Top cover
2 Ambient temp. sensor
3 Ambient temp. sensor clip
4 Back grill
5 Evaporator
6 Coil temp. sensor
7 Temp. sensor clip
8 Sensor casing pipe
9 Upper frame
10 Isolation panel
11 Fan motor bracket
12 Pillar
13 Fan motor
14 Left panel
15 Fan blade
16 Front panel
17 Controller box
18 Ventilation grid
19 Water proof box
20 Controller
21 Reactor
22 Anti-vibration hammer
23 Compressor heating belt
24 Compressor
25 N/A
26 N/A
27 Base tray
28 Terminal board
29 Right panel
30 Clip
31 Pressure gauge
32 5-seat terminal
NO. Spare parts
33 Transition pipe
34 Pipe (Titanium exchanger to Capillary )
35 Capillary
36 Low pressure switch
37 Exhaust temp. sensor
38 Exhaust pipe
39 Pipe (4-way valve to exchanger)
40 High pressure switch
41 Pipe (4-way valve to collective piping)
42 4-way valve
43 Drainage plug
44 Water inlet temp. sensor
45 Water inlet temp. sensor clip
46 Titanium heat exchanger
47 O' ring
48 Blue rubber ring
49 Water connection
50 Red rubber ring
51 Water outlet temperature sensor
52 Sealing ring for water flow switch
53 Water flow switch
54 Magnetic ring
55 Electric box
56 Magnetic ring
57 PCB
58 Electric box cover
59 Transition pipe
60 Pipe (Titanium exchanger to Capillary )
61 Capillary
62 Low pressure switch
63 Exhaust temp. sensor
