To adjust the vertical angle of the platform up to 90
degrees, turn the platform (Figure 4, number 3).
Focus adjustment
To adjust the camera zoom and focus, see Figure 5 and
do the following:
Table 3: Description of zoom and focus adjustment in
Figure 5
1.
Zoom ring thumbscrew for VA2 and focus ring for VA9
lens.
2.
Focus ring thumbscrew for VA2 and zooming ring for
VA9 lens.
1. Loosen the zoom ring thumbscrew.
2. Turn the zoom ring to set the desired zoom.
3. Tighten the zoom ring thumbscrew.
4. Loosen the focus ring thumbscrew.
5. Turn the focus ring to set the desired focus.
6. Tighten the focus ring thumbscrew.
Connect the monitor
Program the cameras by attaching a standard video
monitor to the system.
To connect the monitor, do the following:
1. Plug the monitor output cable (Figure 2) to the video
monitor output connector (Figure 1).
2. Connect the BNC cable to the video monitor.
3. Press Enter (Figure 3) to display the Setup menu.
Programming
The camera is configured through the setup menus
which appear on-screen. See Figure 6.
To access and navigate the menus, press and hold the
center of the OSD control pad (Figure 3). Press Up or
Down on the control pad to move between items, and
press Enter (center of the control pad) to select the item.
Press Right or Left on the control pad to select the
different options available for the item.
You can return to the previous menu from any of the
menus (except the Main menu) by selecting the Previous
page option.
The menu map is shown on the back page.
Refer to the User Manual for detailed programming
instructions.
Table 4: Main menu options
Menu option
Description
Preset
Preset settings.
Setup
Camera ID, Line Lock, motion detection, and
WDR settings.
Viewing
Flip and resolution settings
Exposure
AGC, AE preferences, range control, shutter
limit, frame RPT, and B/W control settings.
White balance
White balance settings.
P/N UVD-XP3DNR quick install_092009-Multilingual • REV 2.0 • ISS 19AUG11
Menu option
Description
Save/Restore
Save and restore user and factory settings.
Specifications
Electrical
Power Input
Power consumption
Environmental and physical
Weight
Dimensions
Operating Temperature
Weather resistant
Regulatory information
Copyright
© 2011 UTC Fire & Security. All rights
reserved.
Trademarks and
Interlogix, UltraView names and logos are
patents
trademarks of UTC Fire & Security.
Other trade names used in this document
may be trademarks or registered
trademarks of the manufacturers or vendors
of the respective products.
Manufacturer
UTC Fire & Security Americas Corporation,
Inc.
2955 Red Hill Avenue, Costa Mesa, CA
92626-5923, USA
Authorized EU manufacturing
representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, The
Netherlands
Certification
FCC compliance
Class A:
and found to comply with the limits for a
Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference when the equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case
the user will be required to correct the
interference at his own expense.
European Union
12004/108/EC (EMC directive):
UTC Fire & Security declares that this
directives
device is in compliance with the essential
requirements and other relevant provisions
of Directive 2004/108/EC.
2002/96/EC (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste in
the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new
12 VDC or 24 VAC
3W (DC); 2.4 W (AC)
33.8 oz. (958 g)
5.22 x 4.11 in. (133 x 105 mm)
-58 to +122°F ( + -50 to
+50°C)
IP66
N4131
This equipment has been tested
Hereby,
