1.3 Intended use:
This device is a spotlight that can create decorative lighting effects This device is for professional applications, eg.
stages, discos, theaters, etc. and is not suitable for room lighting in households This product is approved for
AC100-240V, 50/60 Hz AC only and is designed for indoor use only When choosing the installation location, make
sure that the device is not exposed to excessive heat, moisture and dust. The ambient temperature must be
between -5 ° C and + 45 ° C. Keep the device away from direct sunlight and heating elements. Do not operate the
device until you have familiarized yourself with its functions. Do not allow the device to be operated by persons
who are unfamiliar with the device. Please note that unauthorized modifications of the device are prohibited for
safety reasons. If use the device non accordance with this user manual it may damage the device and void the
warranty. In addition, any usage non accordance with this user manual can cause hazards, such as short circuit,
fire, electric shock, crashes, etc.
Part 2: Installation:
Unpack the device and carefully check if it has any damage before using it. Place the unit in a suitable location or
hang it on a suitable crossbar. For suspended mounting, the device must be secured with an approved safety
rope. In addition, the mounting bracket must be screwed with the enclosed screws and tightened! Then connect
the device to the mains and, if necessary, connect a DMX cable and connect it to other devices or a DMX
controller. More about DMX or Master / Slave operation see under Part 3.
During installation, the regulations of BGV C1 (formerly VBG 70) and DIN 15560 must be observed! The
installation should be done by authorized specialists!
IMPORTANT! Overhead mounting requires a high level of experience. This includes knowledge of the calculation
of the load capacity, installation material used and safety inspections of the material used and the device, but the
required experience is not limited only to this. If you do not have appropriate qualifications, then you should not do
the installation by yourself. Instead of installation by yourself, hire a professional installer. Improper installation can
result in injury and / or property damage.
NOTE!
Use of stands.
When mounting the unit on a lighting stand, make sure it is secure and that the weight of the unit does not
exceed the permitted loading capacity of the lighting stand
.
NOTE!
Please note that this device must not be connected to a dimmer.
