8. „Color fading" Mode: Push the "MODE" button until the display shows "Fd.01". The color fade mode is
active. Use the "UP" and "DOWN" buttons to change the speed (Fd.01 = slow, Fd.99 = fast). To program
the programs with a strobe effect, Push the "SETUP" button to enter the submenu for the strobe effect.
Now you can set the flash speed from slow to fast with the "UP" and "DOWN" buttons (FS.00 to FS.15).
9. „DISPLAY" Mode: ush the "MODE" button until the display shows "don". With "UP" and "DOWN" buttons
you can select between "don" and "doff". At „don" mode the display always on. At "doff" the display turns off
after about 20 seconds. It flashes first. Push "SETUP" button, the display shows "Stnd". The "UP" and
"DOWN" buttons now allow you to reverse the display (for example, for a head over-installation)
Push "SETUP" again to display "dEFA". The display starts to flash. If you now push and release the "UP"
and DOWN "buttons at the same time, the headlamp has been reset to factory settings.
10. IR-REMOTE:
Push the "MODE" button until the display shows "Ir". The menu for the IR remote control is called up. Push
"ENTER" to select between "Iron" or "IroF". With the "UP" and "DOWN" buttons you can now activate the
IR remote control "ON" or deactivate "OFF".

3.2 DMX channel owerview:

NOTE:
Basic knowledge of DMX-512 is required for DMX control!
CH6 Mode (6 channels)
Kanal
1
2
3
4
5
6
CH7 Modus (7 Kanäle)
Kanal
1
2
3
4
5
6
7
CH8 Modus (8 Kanäle)
Kanal
1
2
3
4
5
6
7
8
CH9 Modus (9 Kanäle)
Kanal
1
2
3
4
Wert
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
Value
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
Value
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
0 – 255
Value
0 – 255
0 – 255
0 – 255
0 – 255
24
Function
Rot from 0 – 100%
Greenfrom 0 – 100%
Blue from 0 – 100%
White from 0 – 100%
Amber from 0 - 100%
UV from 0 – 100%
Function
Red from 0 – 100%
Green from 0 – 100%
Blue from 0 – 100%
White from 0 – 100%
Amber from 0 - 100%
UV from 0 – 100%
Master Dimmer from 0 – 100%
Function
Red from 0 – 100%
Green from 0 – 100%
Blue from 0 – 100%
White from 0 – 100%
Amber from 0 - 100%
UV from 0 – 100%
Master Dimmer from 0 – 100%
Color Macros (check the table)
Function
Red from 0 – 100%
Green from 0 – 100%
Blue from 0 – 100%
White from 0 – 100%
