Display on/off
OTHER
MODE
IR remote
function on/off
Display
normal/invers
e
Initialization
mode
1. „DMX" Mode: Press the "MODE" button until the display shows "A001". The DMX mode is active and set
to start address 001. To change the start address, use the "UP" and "DOWN" buttons. Press the "Setup"
button to enter the selection menu for the number of channels. With the "UP" and DOWN "buttons you can
now choose between 6, 7, 8, 9 or 11 channels. In DMX mode, you can recall the full range of the device.
We recommend this mode to take full advantage of all the features of the "SLIMPAR710PRO". Below you
will find an overview of the exact channel assignmen
2. „MASTER/SLAVE" Mode: Press the "MODE" button until the display shows "Slav". The device can also
be used in master / slave mode. With this mode you can connect several "SlimPAR 126 PRO" with XLR
cables, One device is the master and all further devices are the slaves. No matter which function you set
up for the master, slaves will work synchronously with the master.
3. „Fan" Mode:Press the "MODE" button until the display shows "FAN SPEED". Now you can define the fan
speed mode with the "UP" and "DOWN" buttons. "Fan0" - fan speed is temperature controlled. "Fan1- the
fan runs permanently with medium speed.
4. „Manual Dimmer" Mode: Press the "MODE" button until the display shows "r.XXX". The manual free color
mixing mode is active. With the "UP" and "DOWN" buttons you can now adjust the brightness of red color
from "001" to "255". Push the "SETUP" button to adjust the green color as well (the display shows (G.000
to G.255). Push the "SETUP" button to adjust the blue color as well (the display shows (B.000 to B.255).
Push the "SETUP" button to adjust the white color as well (the display shows (W.000 to W.255). Push the
"SETUP" button to adjust the amber color as well (the display shows (A.000 to A.255). Push the "SETUP"
button to adjust the UV color as well (the display shows (u.000 to u.255). After set up the UV color, you will
get to the Submenu for the strobe effect Now you can set the flash speed from slow to fast with the "UP"
and "DOWN" buttons (FS.00 to FS.15).
5. „SOUND" Mode: Push the "MODE" button until the display shows "So01" (So = Sound, 01: 1 to 16 for the
selected program). You can adjust the sensitivity of the internal microphone by push "Setup" for the display
to show "SJ-1". With the "UP" and "DOWN" buttons you can adjust the sensitivity from 1 - 8, where 8 is the
highest sensitivity and 1 the lowest sensitivity. Silent Scene: "Son" and "SoFF" - Silent mode refers to
music-controlled operation. If the silent mode is deactivated "SoFF", the current program of the device
continues to run slowly if no further music signals (bass impulses) are received. If the silent mode is
activated "Son", the light beams of the device switch off (BLACKOUT) if no further music signals (bass
impulses) are received.Drücken
6. „Static color" Mode: Push the "MODE" button until the display shows "CL-XX". The static color mode is
active. With "UP" and "DOWN" buttons you can now set a static color of your choice from "CL-00" to "CL-
63". Push the "SETUP" button to enter the submenu for the strobe effect. Now you can set the flash speed
from slow to fast with the "UP" and "DOWN" buttons (FS.00 to FS.15)
„Color changing" Mode: Push the "MODE" button until the display shows "AJ.XX". The device now plays
7.
one of the 16 color change programs. Use the "UP" and "DOWN" buttons to select the requested
programs. Push the "Setup" button for the submenu for the operating speed. Use the "UP" and "DOWN"
buttons to change the speed (SP.01 = slow, SP.16 = fast) Push "SETUP" again and will display "A-JF". If
you push "SETUP" again, the current program will be displayed in fade mode. Even if the mode is set to
"AF" (Auto Fading), you can use the "UP" and "DOWN" buttons to choose the programs 1 to 16.
don: LED display is always on. doFF: LED
display turns out after 20 seconds.
IR remote on or off
Display inverse
Set up the factory default settings
