zes the battery.
a) If the jump start was successful, pull out the
mains plug and disconnect fi rst the black
charging cable and then the red charging
cable (see section 5.5).
b) If the jump start was unsuccessful, charge
the battery again for at least 15 minutes with
a high charging current. Then repeat the jump
start process from point 2 if the LED display
indicates at least 11.5 V (23 V).
3. You can repeat the jump start process twice. If
the 3rd jump start attempt is also unsuccess-
ful, do not try it again. The jump start function
is unable to provide suffi cient assistance for
the battery in the jump start process.

6. Safety devices

1. The charger is equipped with electronic
protection against overload, short circuit and
swapped poles. A short circuit on the termi-
nals or swapped poles (+/- terminals at the
battery poles the wrong way round) is indica-
ted by the error message "ERR" (see section
5.1).
2. Depending on the equipment, there are also
fuses inside the equipment for additional
electronic protection. In the event of a fault,
fuses inside the equipment can only be re-
placed by an after sales service outlet. Faulty
fuses must be replaced with ones of the same
rating.
3. There is a miniature fuse on the rear of the
equipment. In the event of a fault, the user
can replace this fuse with one of the same
rating. To do so, use a suitable screwdriver to
turn the top part of the fuse holder to the left.
After replacing the fuse, turn the top part to
the right again.
7. Maintenance and care of the
battery
•
Ensure that your battery is always fitted se-
curely.
•
A perfect connection to the cable network of
the electrical system must be ensured at all
times.
•
Keep the battery clean and dry. Apply a thin
coating of grease to the connection terminals
using an acid-free, acid-resistant grease
(Vaseline).
Anl_CE_BC_30_M_SPK9.indb 18 Anl_CE_BC_30_M_SPK9.indb 18
GB
•
Check the level of the acid in batteries that
are not maintenance-free versions approxi-
mately every 4 weeks and top up with distilled
water if necessary.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
•
The charger should be placed in a dry room
for storage. Any corrosion must be cleaned
off the charging terminals.
8.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8.3 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
•
Type of machine
•
Article number of the machine
•
Identification number of the machine
•
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
